Sintered Alnico Permanent Alloy

Sintered Alnico Permanent Alloy

Characteristics:

  1. Suitable for small volume magnets with complex shape
  2. Compact crystal, high intensity
  3. Regular shape, precision size
  4. Even elements, stable performance
  5. Suitable for compound magnet
  6. Excellent temperature stability (temp. coefficient of Br is the smallest among all of the other permanent magnets.)

Application:

  1. Inner magnetic voltmeter/ammeter, electronic type power energy measuring instrument, avometer, flow meter
  2. A wide range of magnetic sensor, polarized relay, temperature and pressure controller
  3. Buzzer of mobile phone, hearing aids, mini speaker
  4. Lighter of automobile, odometer of automobile and motorcycle, permanent motor, adsorptive appliance
  5. Widely applied in high stability fields as aviation, spaceflight and military technology.

Typical Magnetic Performance Range for Sintered Alnico

Grade

Br

Hc

(BH)max

Tc

Tw

Temp. Coefficient

MMPA Equivalent

Remark

mT

KGs

KA/m

Oe

KJ/m3

MGOe

%/

FLN8

550

5.5

42

530

9.0

1.13

760

450

-0.022

[S.Alnico3]

Isotropy

FLNG12

700

7

48

600

12.4

1.55

810

450

-0.014

S.Alnico2

FLNGT18

580

5.8

90

1130

18.0

2.20

860

450

-0.020

[S.Alnico7]

FLNG34

1100

11

48

600

34.0

4.25

890

450

-0.016

S.Alnico5

Anisotropy

FLNGT28

1000

10

56

700

28.0

3.50

850

450

-0.020

S.Alnico6

FLNGT38

800

8

120

1500

38.0

4.75

850

450

-0.020

S.Alnico8

FLNGT42

850

8.5

120

1500

42

5.25

820

450

-0.020

FLNG33J

680

6.8

140

1750

33.0

4.13

850

450

-0.025

S.Alnico8HC



Demagnetization Curve of Sintered Alnico Permanent Alloy

Demagnetization Curve of Sintered Alnico Permanent Alloy
